500ml PET Bottle 12 Head 4000B/h Automatic Water Bottle Filling Machine for Pure Water

500ml PET Bottle 12 Head 4000B/h Automatic Water Bottle Filling Machine for Pure Water

Quick Detail:

• Type: Filling Machine
• Condition: New
• Application: Water (mineral water, pure water)
• Packaging Type: Bottles,
• Automatic Grade: Automatic
• Driven Type: Electric
• Voltage: 220/380V
• Power: 2.2KW
• Place of Origin: Jiangsu, China (Mainland)
• Brand Name: Hyford
• Model Number: CGF16-12-6
• Weight: 2000kg
• Certification: CE, ISO, SGS, BV
• After-sales Service Provided: Engineers available to service machinery overseas
• Material: High quality SUS304 stainless steel
• Filling Principle: Normal Pressure, Gravity Filling
• Number of Washing Heads: 16
• Number of Filling Heads: 12
• Number of Capping Heads: 6
• Production Capacity: 4000B/h (500ml)
• Shipment: by Sea/Train

Description:

This water filling machine contains washing, filling and capping with complete automation. It is suitable for filling all kinds of water such as mineral water, pure water, still water and tab water into polyester bottles and PET bottles. The bottleneck blocking makes the process of changing bottles easily by only adjusting the height of the conveyor chain. The filling process adopts micro-pressure technology, which makes filling process faster and more reliable.

Specifications:

Automatic washing filling and capping line--Main data

Competitive Advantage:

1. Air Conveyor connects with bottle-in starwheels. Bottle neck holding transferred.

2. Clamp transferring technology varied bottle types.

3. With little abrasion. Stable Transferring. Easy to change bottles.

4. With ring type pressure bearing hydraulic cylinder.

5. With high filling speed and exact liquid level.

6. Excellent Stainless Steel. Electric Components are of world known brand. All achieve national sanitary standard.

7. The bottle-out starwheel is of screwdown shape. No need to adjust transferring chain's height to different bottles.

8. Easy to operate and maintain.

9. PLC and transducers and other main electric parts are of world famous brands, such as OMRON, MITSUBISHI etc.

Hyford keeps 100% confident and try our best ability to satisfy customers' requirements with their selected products. Additionally, Hyford owns a professional aftersale customer service team. Therefore, If you have any inquiries or questions, please visit our store, have a look other products and leave your message. Your message will be highly appreciated! Welcome to Hyford!

Flow Chart of the Water Filling Machine (Water Filling Line)

Packing of the Water Filling Machine (Water Filling Line)
